HDPE Geomembrane As Agriculture Pond Liner

Characteristics:

1. Good flexibility

2. For service temperature range:-70°C~110°C

3. Corrosion resistance, aging resistance

4. Excellent environmental stress cracking resistance property

5. High tensile strength and elongation

Description:

HDPE smooth geomembrane is produced from high density polyethylene resin by film-blowing process, adding carbon black, antioxidant, anti-aging and UV-resistance component. Now it is the most widely used products for solid waste containment (such as landfill liners), mining and water containment applications.

Item
Value
Thickness,mm
0.75
1.0
1.25
1.5
2.0
2.5
3.0
Density,g/cm3
≥0.94
Tensile yiedl strength,N/mm
≥11
≥15
≥18
≥22
≥29
≥37
≥44
Tensile breaking strength,N/mm
≥20
≥27
≥33
≥40
≥53
≥67
≥80
Elongation at yield, %
≥12
Elongation at break,%
≥700
Tear Resistance,N
≥93
≥125
≥160
≥190
≥250
≥315
≥375
Puncture Resistance,N
≥240
≥320
≥400
≥480
≥640
≥800
≥960
Stress Crack Resistance,h
≥300
Carbon Black Content, %
2.0-3.0
Carbon Black Dispersion
1 or 2
Standard OIT,min
≥100
High Pressure OIT,min
≥400
Product Application

Environmental protection projects:
Landfill,sewage treatment plants,power plant regulating pools,industrial and hospital solid wastes,etc.

Aquaculture projects:
fish ponds,shrimp ponds,industrialized aquaculture ponds,etc.
View File

Agriculture:
Seepage control of reservoirs, reservoirs, irrigation systems, etc.

Petrifaction:
Chemical plant, refinery, storage tank seepage control, chemical reaction tank,etc.
View File
